Introduction of trolley resistance furnace

Zoe Jia 2023-11-23 09:27:39
The trolley resistance furnace is a national standard energy-saving periodic operation furnace with ultra-energy-saving structure and fiber structure, which saves up to 60% of electricity. The exclusive production adopts composite high-alumina porcelain nail group, trolley anti-impact sealing brick, automatic sealing trolley and furnace door, integrated rail, no foundation installation, and can be used on the horizontal ground. It is mainly used for quenching, annealing, aging and heat treatment of various mechanical parts such as high chromium and high manganese steel castings, ductile iron, rolls, steel balls, 45 steel, stainless steel, etc.

The lining adopts the full fiber structure, which is about 60% energy-saving compared to the brick furnace, and uses high-quality long fiber blanket as raw material, and uses special equipment to make the specifications of large plates according to the size of the furnace, and leaves a certain amount of compression in the processing process to ensure that after the module is completed, each ceramic fiber block expands in different directions, so that the modules are squeezed into a whole without gaps, so as to achieve a good heat storage effect, and the product is convenient and fast to construction, and can be directly fixed on the stainless steel anchor round nail of the steel plate of the furnace shell. Compared with other products, the advantages are low thermal conductivity, low heat capacity, excellent corrosion resistance, excellent thermal stability, thermal shock resistance, thermal insulation, and the anchor is set on the cold surface of the furnace body, which improves the high temperature strength of the fiber.
